Model
PRV-5088R3-W/R/G/B/Y/UV/IR
|
Lighting |
|||||||
|
Mode |
Vertical Lighting |
||||||
|
Radiate Angle |
0° |
||||||
|
Working Distance |
Dark-field < 150 mm |
||||||
|
Color |
|
|
|
|
|
|
|
|
Wave Length (nm) |
- |
490 |
545 |
585 |
660 |
1100 |
400 |
|
LED Life |
Over 20,000 hr*1 |
Over 30,000 hr*1 |
|||||
|
Electrical |
|||||||
|
Power Consumption |
19V/ 3.8W |
19V/ 3.8W |
20V/ 4W |
12V/ 2.4W |
13V/ 2.6W |
9V/ 1.8W |
13V/ 2.6W |
|
Drive Current |
200 mA |
||||||
|
Cable Length |
300 mm |
||||||
|
Connector |
SMP-03V, 3pin (Male) for Constant Current Drive or SMP-02V, 2pin (Male) for Constant Voltage Drive |
||||||
|
Environmental |
|||||||
|
Operation |
Temp. 0~40 ℃, Humidity 20~85% (No condensing) |
||||||
|
Storage |
Temp. -20~60 ℃, Humidity 20~85% (No condensing) |
||||||
|
Power Supply Unit |
|||||||
|
Model |
|||||||
|
Mechanical |
|||||||
|
Dimension |
Outer Ø 88 mm, Inner Ø 50 mm, Height 25 mm |
||||||
|
Available Lens Ø |
28mm, 30mm, 32mm |
||||||
|
Housing |
Plastic molding (PC, Polycarbonate) |
||||||
|
Weight |
115 g |
||||||
|
(Remark *1：LED life decade to 50% of initial intensity.) |
|||||||
|
|||||||||||
|
|||||||||||
|
|||||||||||
