Lighting

Mode

Wide-angle Lighting

Radiate Angle

120°

Working Distance

< 20 mm

Color

Wave Length (nm)

-

490

545

585

660

1100

400

LED Life

Over 20,000 hr^*1

Over 30,000 hr^*1

Electrical

Power Consumption

19V/ 3.8W

19V/ 3.8W

20V/ 4W

12V/ 2.4W

13V/ 2.6W

Drive Current

150 mA

Cable Length

300 mm

Connector

SMP-03V, 3pin (Male)  for Constant Current Drive or

SMP-02V, 2pin (Male)  for Constant Voltage Drive

Environmental

Operation

Temp. 0~40 ℃, Humidity 20~85% (No condensing)

Storage

Temp. -20~60 ℃, Humidity 20~85% (No condensing)

Power Supply Unit

Model

PC-24V12W series

Mechanical

Dimension

Outer Ø 88 mm, Inner Ø 50 mm, Height 25 mm

Available  Lens Ø

28mm, 30mm, 32mm

Housing

Plastic molding (PC, Polycarbonate)

Weight

65 g

(Remark *1：LED life decade to 50% of initial intensity.)
